Product Description


Truck ModelZZ1107G4215C1(Left Hand Drive )
Truck BrandSINOTRUK-HOWO
Dimension (LxWxH) (unloaded)mm7445×2400×2750
Tank Volume7m³1 separated tank, head 4mm, body 4mm, material Q23
5Subsea valve: 1 positionFlow meter: return to zero flow meter
Pump system piping system: 2.5 inchesRefueling gun: 1 inchReel: 1 inch * 10 meters
Other: pressure unloading, gravity unloading, towing wire, fire caps, fire extinguishers. Vehicle spray wax.
Approaching angle/ Departure angel (°)27/20
Overhang (front/rear) (mm)1240/2005
Wheel base (mm)4200
Max. Driving speed (km/h)95
Front axle loading capacity (kg)3200
Rear axle loading capacity(kg)8000
Curb weight (kg)5735
Gross vehicle weight10000
Cab2080 Extended cab,with A/C
Engine ModelModelYUCHAI brand,YC4E140-33, 140hp
Rated Power(kw/rpm)105/2800
ClutchDiaphragm spring clutch,single plate
TransmissionModelWLY651,6F&1R
Brake systemService brakeDual circuit air brake
Parking BrakeSpring energy, compressed air operating on rear wheels
Steering systemModelPower steering,Adjustable steering wheel.(left hand driving)
Front axle(3.2T)Forging I-beam,Drum brake.
Rear axle(8.0T) Pressed welding axle housing drum brake.
Tire8.25R20 Radial tire 6 pieces with 1 Spare tire.
Electrical systemTypeSINOTRUK CAN bus system with VCO instrument
Voltage12V,
Batteries2*12V, 120 Ah
Alternator28V/35A
Starter4.5Kw
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.
Oil Tank220L fuel tank
PackingNude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice
