| Truck Model | ZZ1257V3847B1 |
| Truck Brand | SINOTRUK-HOWO |
| Dimension (LxWxH) (unloaded)mm | 8850×2550×3950 |
| Tank volume(m³) | Mixing Volume(M³)：10m³ Stuffing Volume(%)：59.63Feeding Speed(M³/min):≥3 Discharging Speed(M³/min):≤2Discharge Residue(%):≤0.2 Slump Scope(mm):50～220Drum Speed( Min)：0～16 Water supply Syste：400L/PneumaticDrum Material：Head 8mm;Body 5mm;Blade:3mm、4mm、5m |
| Approaching angle/ Departure angel (°) | 16/24 |
| Overhang (front/rear) (mm) | 1500/2340 |
| Wheel base (mm) | 3800+1400 |
| Max. Driving speed (km/h) | 95 |
| Front axle loading capacity (kg) | 9500 |
| Rear axle loading capacity(kg) | 2*16000 |
| Curb weight (kg) | 13220 |
| Gross vehicle weight | 30000 |
| Cab Model | SINOTRUK HW76 Lengthen cab,single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,air conditioner |
| Engine Model | Model | WP12.400E201(EURO II),400hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Rated Power(kw/rpm) | 294/2100 |
| Make WEICHAI, Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan |
| Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance |
| Transmission | Model | SINOTRUK HW19710 transmission ,10 forward and 2 reverse |
| Brake system | Service brake | Dual circuit compressed air brake |
| Parking Brake(emergency brake) | Spring energy, compressed |
| Steering system | Model | BOSCH Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving) |
| Front axle | SINOTRUK VGD95 Front Axle,new 9.5-ton front axles of equipped with drum brakes. |
| Rear axle | SINOTRUK 2*16000 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.8;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers. |
| Wheels &Tire | Rims:8.5-20 10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.Option:12R22.5 tubeless;315/80R22.5 tubeless;13R22.5 tubeless. |
| Electrical system | Electrics Operating voltage | 24V,negative grounded |
| Starter | 24V,7.5 Kw |
| Alternator | 3-phase,28V,1500 W |
| Batteries | 2x12 V,165 Ah |
| horn,headlamps,fog lights,brake lights,indicators and reverse light. |
| Oil Tank | 400L fuel tank |
| Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity. |
| The manufacturer reserves the right of technical alteration /change for better improvement without prior notice |
